Specifikáció

Wifi	Wi-Fi 7
Foglalat	AM5
Chipset	X870E
M2 csatlakozó	5
Memória típus	DDR5
Memóriahelyek	4
Max RAM	256 GB
SATA csatlakozó	2
Form	ATX
Max RAM frekv	9000 MHz
PCIe	5.0

További Specifikáció

Depth	244
Width	305
Height	35
Weight	3.78
Line In	Yes
Bios Type	UEFI AMI
Bluetooth	Yes
Audio Chip	Realtek ALC1220-VB/ESS 9118
Dmi Version	2.7
Raid Levels	0, 1, 5, 10
Acpi Version	5.0
Battery Type	CR2032
Cooling Type	Passive
Ethernet Lan	Yes
Hdcp Version	2.3
Hdmi Version	2.1
Raid Support	Yes
Component For	PC
Package Depth	310
Package Width	340
Tpm Connector	Yes
Battery Weight	3
Lan Controller	Realtek RTL8126, Realtek RTL8127
Package Height	92
Package Weight	4.33
Product Colour	Black
Smbios Version	2.7
Spdif Out Port	Yes
Wifi Standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Directx Version	12.0
Memory Channels	Dual-channel
Screws Included	Yes
Warranty Period	3 year(s)
Antenna Included	Yes
Battery Capacity	220
Bios Memory Size	512 Mbit
Bundled Software	Norton® Internet Security (OEM version)
Bluetooth Version	5.4
Clear Cmos Button	Yes
Clear Cmos Jumper	Yes
Country Of Origin	Taiwan
Cpu Fan Connector	Yes
Ecc Compatibility	Non-ECC
Headphone Outputs	1
Power Source Type	ATX
Batteries Included	Yes
Battery Technology	Lithium-Manganese Dioxide (LiMnO2)
Maximum Resolution	4096 x 2304
Rgb Led Pin Header	Yes
Usb 2 0 Connectors	2
Displayport Version	1.4
Hdmi Ports Quantity	1
Pc Health Monitoring	CPU, Fan, Temperature, Voltage, Water cooling
Wifi Ap Antenna Jack	2
Audio Output Channels	5.1 channels
Front Panel Connector	Yes
Wlan Controller Model	MediaTek MT7927
Ethernet Interface Type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Number Of Battery Cells	1
1st M 2 Largest Key Size	2580
2nd M 2 Largest Key Size	2280
3rd M 2 Largest Key Size	2280
4th M 2 Largest Key Size	2280
5th M 2 Largest Key Size	2280
Ethernet Lan Rj 45 Ports	2
Usb 3 2 Gen 1 Connectors	2
Digital Audio Optical Out	1
Eps Power Connector 8 Pin	Yes
Number Of Hd Ds Supported	2
Atx Power Connector 24 Pin	Yes
Lithium Weight Per Battery	0.07
Usb 3 2 Gen 2x2 Connectors	1
Chassis Intrusion Connector	Yes
Compatible Processor Series	AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Front Panel Audio Connector	Yes
Usb4 Gen 2x2 Ports Quantity	2
Number Of Cpu Fan Connectors	2
Number Of Rgb Led Pin Headers	5
Pci Express X16 Gen 4 X Slots	1
Pci Express X16 Gen 5 X Slots	2
Supported Storage Drive Types	HDD & SSD
Number Of Water Pump Connectors	2
Number Of Chassis Fan Connectors	6
Products Per Shipping Inner Case	1 pc(s)
Number Of Noise Detection Headers	1
Number Of Storage Drives Supported	7
Supported Storage Drive Interfaces	M.2, PCI Express 4.0, PCI Express 5.0, SATA III
Usb 3 2 Gen 2 Type A Ports Quantity	7
Usb 3 2 Gen 2 Type C Ports Quantity	1
Windows Operating Systems Supported	Windows 11 x64
Number Of Eps Power Connectors 8 Pin	2
Number Of Temperature Sensor Headers	2
Usb 3 2 Gen 2x2 Type C Ports Quantity	1
1st M 2 Highest Pci Express Generation	5.0
2nd M 2 Highest Pci Express Generation	5.0
3rd M 2 Highest Pci Express Generation	4.0
4th M 2 Highest Pci Express Generation	4.0
5th M 2 Highest Pci Express Generation	4.0
