Depth	304.8
Width	243.8
Bios Type	UEFI AMI
Bluetooth	Yes
Raid Levels	0, 1, 10, 5
Acpi Version	6.5
Ethernet Lan	Yes
Hdmi Version	2.1
Raid Support	Yes
Component For	PC
Microphone In	Yes
Lan Controller	Realtek RTL8126
Product Colour	Black
Spdif Out Port	Yes
Memory Channels	Dual-channel
Bios Memory Size	512 Mbit
Bluetooth Version	5.4
Cpu Fan Connector	Yes
Ecc Compatibility	Non-ECC
On Board Graphics	No
Usb 2 0 Connectors	6
Atx Power Connector	Yes
Displayport Version	1.4
Eps Power Connector	8-pin
Hdmi Ports Quantity	1
Pc Health Monitoring	CPU, Fan, Temperature, Voltage
Audio Output Channels	7.1 channels
Total Sata Connectors	4
Display Ports Quantity	2
Usb 2 0 Ports Quantity	4
1st M2 Largest Key Size	2280
2nd M2 Largest Key Size	2280
3rd M2 Largest Key Size	22110
Ethernet Interface Type	5 Gigabit Ethernet
Number Of Hdds Supported	4
Usb 3 2 Gen 1 Connectors	4
Usb 3 2 Gen 2 Connectors	1
Motherboard Chipset Family	AMD
Compatible Processor Series	AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Usb4 Gen 2x2 Ports Quantity	1
Pci Express X16 Gen 3 X Slots	1
Pci Express X16 Gen 4 X Slots	1
Pci Express X16 Gen 5 X Slots	1
Supported Storage Drive Types	HDD & SSD
System Management Bios Version	3.7
Number Of Storage Drives Supported	7
Supported Storage Drive Interfaces	M.2, SATA III
Usb 3 2 Gen 1 Type A Ports Quantity	2
Usb 3 2 Gen 2 Type A Ports Quantity	2
Usb 3 2 Gen 2 Type C Ports Quantity	1
1st M2 Highest Pci Express Generation	5.0
2nd M2 Highest Pci Express Generation	4.0
3rd M2 Highest Pci Express Generation	4.0
Usb 3 2 Gen 2x2 Type C Ports Quantity	1

MSI MAG X870E GAMING PLUS MAX WIFI
