Gigabyte
GIGABYTE A520M DS3H V2
MPN: A520M DS3H V2
Build infó
Ajánlott build
PC konfigurációkhoz
Illeszkedés
- mATX formátum
- AM4 kompatibilitás
Árak webshopokban
Legjobb ár
20 830 Ft
MegnézemÁrelőzmények
Specifikáció
| Foglalat | AM4 |
| Chipset | A520 |
| M2 csatlakozó | 1 |
| Memória típus | DDR4 |
| Memóriahelyek | 4 |
| Max RAM | 128 GB |
| SATA csatlakozó | 4 |
| Form | mATX |
| Max RAM frekv | 4733 MHz |
| PCIe | 3.0 |
További Specifikáció
| Hdcp | Yes |
| Depth | 244 mm |
| Width | 244 mm |
| Height | 35 mm |
| Bios Type | UEFI AMI |
| Audio Chip | Realtek ALC887 |
| Raid Levels | 0, 1, 10 |
| Acpi Version | 5.0 |
| Battery Type | CR2032 |
| Cooling Type | Active |
| Ethernet Lan | Yes |
| Hdmi Version | 2.1 |
| Raid Support | Yes |
| Component For | PC |
| Microphone In | Yes |
| Package Depth | 265 mm |
| Package Width | 265 mm |
| Tpm Connector | Yes |
| Battery Weight | 3 g |
| Max Resolution | 5120 x 2880 pixels |
| Package Height | 54 mm |
| Package Weight | 810 g |
| Product Colour | Black |
| Cables Included | SATA |
| Memory Channels | Dual-channel |
| Warranty Period | 3 year(s) |
| Bios Memory Size | 128 Mbit |
| Bundled Software | Norton Internet Security (OEM version), Realtek 8118 Gaming LAN Bandwidth Control Utility |
| Drivers Included | Yes |
| Clear Cmos Button | Yes |
| Clear Cmos Jumper | Yes |
| Country Of Origin | China |
| Cpu Fan Connector | Yes |
| Ecc Compatibility | ECC & Non-ECC |
| Headphone Outputs | 1 |
| Power Source Type | ATX |
| Batteries Included | Yes |
| Battery Technology | Lithium-Manganese Dioxide (LiMnO2) |
| Usb 2 0 Connectors | 1 |
| Usb Connector Type | USB Type-A |
| 12v Power Connector | Yes |
| Atx Power Connector | 24-pin |
| Hdmi Ports Quantity | 1 |
| Number Of M 2 Slots | 1 |
| Power Fan Connector | Yes |
| Ps 2 Ports Quantity | 1 |
| Serial Port Headers | 1 |
| Display Port Version | 2.0 |
| Dvi D Ports Quantity | 1 |
| Pc Health Monitoring | CPU, LED, Power supply, Temperature, Voltage |
| Audio Output Channels | 7.1 channels |
| Front Panel Connector | Yes |
| Total Sata Connectors | 4 |
| Display Ports Quantity | 1 |
| Usb 2 0 Ports Quantity | 2 |
| Ethernet Interface Type | Gigabit Ethernet |
| Number Of Battery Cells | 1 |
| Ethernet Lan Rj 45 Ports | 1 |
| Usb 3 2 Gen 1 Connectors | 1 |
| Digital Audio Optical Out | 1 |
| Discrete Graphics Support | Yes |
| Lithium Weight Per Battery | 0.07 g |
| Motherboard Chipset Family | AMD |
| Compatible Processor Series | AMD Ryzen 3000 Series, AMD Ryzen Threadripper 3000 Series, AMD Ryzen Threadripper PRO 3000 WX-Series |
| Front Panel Audio Connector | Yes |
| Number Of Displays Supported | 3 |
| Pci Express X1 Gen 3 X Slots | 2 |
| Pci Express X16 Gen 3 X Slots | 1 |
| Supported Storage Drive Types | HDD & SSD |
| System Management Bios Version | 2.7 |
| Number Of Eatx Power Connectors | 1 |
| Products Per Shipping Inner Case | 1 pc(s) |
| Supported Storage Drive Interfaces | M.2, SATA III |
| Usb 3 2 Gen 1 Type A Ports Quantity | 4 |
| Windows Operating Systems Supported | Windows 10 x64 |
| Desktop Management Interface Version | 2.7 |
