Wifi	Wi-Fi 6
Foglalat	AM5
Chipset	B840
M2 csatlakozó	2
Memória típus	DDR5
Memóriahelyek	2
Max RAM	128 GB
SATA csatlakozó	4
Form	micro ATX
Max RAM frekv	7600 MHz
PCIe	4.0

Hdcp	Yes
Depth	244
Width	244
Height	35
Weight	1.22
Line In	Yes
Bios Type	UEFI AMI
Bluetooth	Yes
Audio Chip	Realtek ALC897
Dmi Version	2.7
Raid Levels	0, 1, 10
Acpi Version	5.0
Battery Type	CR2032
Cooling Type	Passive
Hdmi Version	2.1
Battery Cells	1
Component For	PC
Microphone In	Yes
Package Depth	268
Package Width	270
Tpm Connector	Yes
Battery Weight	3
Lan Controller	Realtek RTL8125
Max Resolution	4096 x 2160
Package Height	68
Package Weight	1.31
Product Colour	Dark brown
Smbios Version	2.7
Wifi Standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Directx Version	12.0
Memory Channels	Dual-channel
Screws Included	Yes
Antenna Included	Yes
Bios Memory Size	256 Mbit
Bundled Software	Norton® Internet Security (OEM version), LAN bandwidth management software
Bluetooth Version	5.3
Clear Cmos Jumper	Yes
Ecc Compatibility	Non-ECC
Headphone Outputs	1
Power Source Type	ATX
Batteries Included	Yes
Battery Technology	Lithium-Manganese Dioxide (LiMnO2)
Cpu Fan Connectors	2
Ethernet Lan Ports	1
Rgb Led Pin Header	3
Usb 2 0 Connectors	2
12v Power Connector	Yes
Atx Power Connector	Yes
Hdmi Ports Quantity	1
Ps 2 Ports Quantity	1
Display Port Version	1.4
Pc Health Monitoring	Fan, Temperature, Voltage, Water cooling
Wifi Ap Antenna Jack	2
Audio Output Channels	7.1 channels
Front Panel Connector	Yes
Water Pump Connectors	2
Wlan Controller Model	Realtek RTL8851BE
Chassis Fan Connectors	2
Display Ports Quantity	1
Usb 2 0 Ports Quantity	4
Ethernet Interface Type	2.5 Gigabit Ethernet
1st M 2 Largest Key Size	2580
2nd M 2 Largest Key Size	2280
Usb 3 2 Gen 1 Connectors	2
Eps Power Connector 8 Pin	1
Lithium Weight Per Battery	0.07
Compatible Processor Series	AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Front Panel Audio Connector	Yes
Pci Express X16 Gen 3 X Slots	1
Pci Express X16 Gen 4 X Slots	1
Supported Storage Drive Types	HDD & SSD
Supported Storage Drive Interfaces	M.2, PCI Express 4.0, SATA III
Usb 3 2 Gen 1 Type A Ports Quantity	2
Windows Operating Systems Supported	Windows 10 x64, Windows 11 x64
1st M 2 Highest Pci Express Generation	4.0
2nd M 2 Highest Pci Express Generation	3.0

GIGABYTE B840M EAGLE WIFI6
