Specifikáció

Wifi	Wi-Fi 7
Foglalat	AM4
Chipset	B550
M2 csatlakozó	2
Memória típus	DDR4
Memóriahelyek	4
Max RAM	128 GB
SATA csatlakozó	4
Form	ATX
Max RAM frekv	3200 MHz
PCIe	4.0

További Specifikáció

Depth	244 mm
Width	305 mm
Height	35 mm
Weight	2.01 kg
Line In	Yes
Bios Type	AMI
Bluetooth	Yes
Raid Levels	0, 1, 10
Acpi Version	5.0
Battery Type	CR2032
Cooling Type	Passive
Ethernet Lan	Yes
Hdcp Version	2.3
Hdmi Version	2.1
Raid Support	Yes
Component For	PC
Package Depth	294 mm
Package Width	345 mm
Battery Weight	3 g
Lan Controller	Realtek RTL8125
Max Resolution	5120 x 2880 pixels
Package Height	80 mm
Package Weight	2.42 kg
Product Colour	Dark brown
Wifi Standards	Wi-Fi 7 (802.11be), 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Directx Version	12.0
Memory Channels	Dual-channel
Screws Included	Yes
Spd If Out Port	Yes
Warranty Period	3 year(s)
Antenna Included	Yes
Battery Capacity	220 mAh
Bios Memory Size	128 Mbit
Bundled Software	Norton® Internet Security (OEM version)
Bluetooth Version	5.4
Clear Cmos Jumper	Yes
Country Of Origin	China
Cpu Fan Connector	Yes
Ecc Compatibility	ECC & Non-ECC
Headphone Outputs	1
Power Source Type	ATX
Batteries Included	Yes
Battery Technology	Lithium-Manganese Dioxide (LiMnO2)
Rgb Led Pin Header	Yes
Usb 2 0 Connectors	2
12v Power Connector	Yes
Displayport Version	1.4
Hdmi Ports Quantity	1
Pc Health Monitoring	Fan, Temperature, Voltage, Water cooling
Wifi Ap Antenna Jack	2
Audio Output Channels	7.1 channels
Displayports Quantity	1
Front Panel Connector	Yes
Wlan Controller Model	Realtek RTL8922AE
Usb 2 0 Ports Quantity	2
Ethernet Interface Type	2.5 Gigabit Ethernet
Number Of Battery Cells	1
1st M 2 Largest Key Size	25110
2nd M 2 Largest Key Size	22110
Ethernet Lan Rj 45 Ports	1
Digital Audio Optical Out	1
Eps Power Connector 8 Pin	Yes
Atx Power Connector 24 Pin	Yes
Lithium Weight Per Battery	0.07 g
Motherboard Chipset Family	AMD
Compatible Processor Series	AMD Ryzen 5000 Series, AMD Ryzen 4000 Series, AMD Ryzen 3000 Series
Front Panel Audio Connector	Yes
Max Internal Memory Per Slot	32 GB
Number Of Cpu Fan Connectors	2
Pci Express X1 Gen 3 X Slots	2
Number Of Rgb Led Pin Headers	4
Number Of Sata Iii Connectors	4
Pci Express X16 Gen 3 X Slots	1
Pci Express X16 Gen 4 X Slots	1
Supported Memory Clock Speeds	3200,2933,2667,2400,2133 MHz
Supported Storage Drive Types	HDD & SSD
Number Of Water Pump Connectors	2
Number Of Chassis Fan Connectors	4
Products Per Shipping Inner Case	1 pc(s)
Number Of Storage Drives Supported	6
Supported Storage Drive Interfaces	M.2, PCI Express 4.0, PCI Express 3.0, SATA III
Usb 3 2 Gen 1 3 1 Gen 1 Connectors	2
Windows Operating Systems Supported	Windows 11 x64
Number Of Eps Power Connectors 8 Pin	1
System Management Bios Smbios Version	2.7
1st M 2 Highest Pci Express Generation	4.0
2nd M 2 Highest Pci Express Generation	3.0
Parallel Processing Technology Support	Not supported
Desktop Management Interface Dmi Version	2.7
Usb 3 2 Gen 1 3 1 Gen 1 Type A Ports Quantity	3
Usb 3 2 Gen 1 3 1 Gen 1 Type C Ports Quantity	1
Usb 3 2 Gen 2 3 1 Gen 2 Type A Ports Quantity	1
