| Depth | 244 |
| Width | 305 |
| Height | 68 |
| Weight | 1.42 |
| Bios Type | UEFI AMI |
| Bluetooth | Yes |
| Audio Chip | Realtek ALC4080 |
| Raid Levels | 0, 1, 5, 10 |
| Ethernet Lan | Yes |
| Hdmi Version | 2.1 |
| Raid Support | Yes |
| Component For | PC |
| Tpm Connector | Yes |
| Cables Included | SATA |
| Memory Channels | Dual-channel |
| Wi Fi Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Bios Memory Size | 192 Mbit |
| Bluetooth Version | 5.2 |
| Clear Cmos Jumper | Yes |
| Cpu Fan Connector | Yes |
| Ecc Compatibility | Non-ECC |
| Headphone Outputs | 5 |
| Memory Slots Type | DIMM |
| Power Source Type | ATX |
| Unbuffered Memory | Yes |
| Rgb Led Pin Header | Yes |
| Usb 2 0 Connectors | 2 |
| 12v Power Connector | Yes |
| Displayport Version | 1.4 |
| Hdmi Ports Quantity | 1 |
| Number Of M 2 Slots | 3 |
| Thunderbolt Headers | 1 |
| S Pdif Out Connector | Yes |
| Wifi Ap Antenna Jack | 2 |
| Audio Output Channels | 7.1 |
| Displayports Quantity | 1 |
| Front Panel Connector | Yes |
| Usb 2 0 Ports Quantity | 4 |
| Ethernet Interface Type | 2.5 Gigabit Ethernet |
| Ethernet Lan Rj 45 Ports | 1 |
| Number Of Hdds Supported | 4 |
| Eps Power Connector 8 Pin | Yes |
| Harmonized System Hs Code | 84733020 |
| Atx Power Connector 24 Pin | Yes |
| Motherboard Chipset Family | Intel |
| Chassis Intrusion Connector | Yes |
| Compatible Processor Series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold |
| Front Panel Audio Connector | Yes |
| Pci Express X1 Gen 3 X Slots | 2 |
| Pci Express X16 Gen 3 X Slots | 1 |
| Pci Express X16 Gen 5 X Slots | 1 |
| Supported Memory Clock Speeds | 2133,2400,2666,2800,2933,3000,3200,3333,3400,3466,3600,3733,4000,4266,4400,4600,4800,5000,5333 |
| Supported Storage Drive Types | HDD & SSD |
| Number Of Chassis Fan Connectors | 3 |
| Number Of Storage Drives Supported | 7 |
| Supported Storage Drive Interfaces | M.2, PCI Express 4.0, SATA III |
| Usb 3 2 Gen 1 3 1 Gen 1 Connectors | 1 |
| Usb 3 2 Gen 2 3 1 Gen 2 Connectors | 1 |
| Windows Operating Systems Supported | Windows 10 x64, Windows 11 x64 |
| Usb 3 2 Gen 1 3 1 Gen 1 Type A Ports Quantity | 2 |
| Usb 3 2 Gen 1 3 1 Gen 1 Type C Ports Quantity | 1 |
| Usb 3 2 Gen 2 3 1 Gen 2 Type A Ports Quantity | 1 |
| Usb 3 2 Gen 2 3 1 Gen 2 Type C Ports Quantity | 1 |
